UNUSUAL CARS MODEL GUIDE
The Volvo S60 R and V70 R were Volvo’s 300hp all-wheel-drive performance saloon and estate of the 2000s. Unveiled in 2002 for the 2004 model year, both used a turbocharged 2.5-litre five-cylinder engine, electronically controlled AWD, Brembo brakes and the adaptive Four-C chassis.
Quick answer: the S60 R and second-generation V70 R share the same core drivetrain and were produced through the 2007 model year. Six-speed manual cars were rated at 300hp and 400Nm in Volvo’s technical data; early five-speed automatics had torque reduced to 350Nm. Their complexity makes complete maintenance history essential.
From the PCC concept to two production R models
Volvo explored the idea with the S60 Performance Concept Car before revealing the production S60 R and V70 R at the 2002 Paris Motor Show. They followed the 850 T-5R, 850 R and first-generation V70 R but added far more active chassis and driveline technology.
The S60 offered the tidier saloon body and slightly sharper sporting image. The V70 added the load space that made fast Volvos famous, while retaining the same engine, AWD system and three-mode suspension concept.
The B5254T4 five-cylinder engine
The 2,521cc inline-five used variable valve timing, a large turbocharger and twin intercoolers. Volvo’s 2003 technical data quotes 300hp. With the M66 six-speed manual it produced 400Nm from 1,950 to 5,250rpm; the early Geartronic automatic was limited to 350Nm.
Manual acceleration figures were 0-100km/h in 5.7 seconds for the S60 R and 5.9 seconds for the V70 R in Volvo data. These are heavy, refined cars rather than stripped specials, so their performance comes from broad torque and all-weather traction.
Four-C, Haldex AWD and Brembo brakes
Four-C means Continuously Controlled Chassis Concept. Sensors monitor wheel and body movement while electronically controlled dampers adjust continuously. The driver selects Comfort, Sport or Advanced, changing damping strategy and the way associated systems respond.
The Haldex-based AWD system normally favours the front wheels and engages the rear axle as conditions demand. Dynamic Stability and Traction Control works alongside it. Four-piston Brembo calipers and large ventilated discs distinguish the R from ordinary S60 and V70 models.
S60 R and V70 R compared
| Feature | S60 R | V70 R |
|---|---|---|
| Body | Four-door saloon | Five-door estate |
| Engine | 2.5-litre turbocharged inline-five | 2.5-litre turbocharged inline-five |
| Transmission | Six-speed manual or market/year-dependent Geartronic automatic | Six-speed manual or market/year-dependent Geartronic automatic |
| Chassis | Three-mode Four-C, AWD and Brembo brakes | Three-mode Four-C, AWD and Brembo brakes |
| Main appeal | More compact sporting saloon | Performance with full estate-car practicality |
A 2005 model update brought styling and equipment changes, while later automatics moved to a six-speed transmission in relevant markets. Buyers should match specifications to VIN and model year rather than assume every P2 R is identical.
Love cars you don’t see every day?
Get forgotten cars, surprising motoring stories and the most interesting finds from Unusual Cars by email.
Free to join. No spam. Unsubscribe whenever you like. See our privacy policy.
Volvo S60 R and V70 R buying guide
Cooling system and cylinder liners
Start from cold and look for a stable idle, clean coolant, correct temperature and no unexplained pressure or loss. Overheating and aggressive tuning can contribute to cylinder-liner damage, so compression or leak-down testing is sensible when symptoms or modifications raise concern.
AWD, angle gear and sleeve
Confirm that all four tyres match closely in brand, model, size and wear. Test that the rear wheels receive drive and inspect the transfer angle gear, coupling sleeve, propshaft, Haldex unit, pump and differential for leaks, noise and neglected fluid service.
Four-C dampers and suspension
Cycle through all three chassis modes and check for warnings. Leaking electronic dampers, worn top mounts, control-arm bushes and broken springs are expensive when several parts need replacement together.
Transmission, clutch and brakes
Manuals need smooth selection and a healthy clutch and dual-mass flywheel. Automatics should shift consistently when hot and have documented fluid care. Inspect the Brembo calipers, discs, hoses and parking brake rather than pricing them as ordinary V70 parts.
Timing belt, PCV and electronics
Require evidence for timing-belt and auxiliary-drive maintenance. Check crankcase ventilation, turbo hoses, engine mounts and oil leaks, then test climate control, instruments, xenon lights, seats, audio, parking sensors and every warning system.
Why the P2 R cars matter
The S60 R and V70 R represented Volvo’s most ambitious attempt of the period to combine everyday safety and comfort with a highly integrated performance chassis. They also marked the high point of the turbocharged five-cylinder R lineage before Polestar became Volvo’s better-known performance name.
Research sources
- Volvo press material: S60 R and V70 R model overview
- Volvo technical data: S60 R and V70 R, February 2003
- Volvo technical training: Four-C active chassis
- Autocar: Volvo S60 R used buying guide
Continue the Volvo story
Explore the Rare & Performance Volvos hub, then compare the Volvo 850 T-5R and R guide and the Volvo 240 Turbo guide.
Frequently asked questions
How much power do the Volvo S60 R and V70 R have?
Volvo quoted 300hp. Manual cars produced 400Nm, while early five-speed automatics were limited to 350Nm.
What is Volvo Four-C?
Four-C is an electronically controlled damping system with Comfort, Sport and Advanced settings on the R models.
Are the S60 R and V70 R four-wheel drive?
Yes. Both use an electronically controlled Haldex-based all-wheel-drive system.
What is the difference between an S60 R and V70 R?
They share the core engine, drivetrain, brakes and chassis technology; the S60 is a saloon and the V70 is an estate.
What should be checked before buying a P2 Volvo R?
Check cooling and engine health, AWD operation, angle gear and sleeve, Four-C dampers, transmission, Brembo brakes, timing-belt history, crankcase ventilation and electronics.
